LADDER PLATFORM / STAGING SYSTEM

SAVE ON SCAFFOLDING COSTS!

Our ladder platform / staging is designed to provide a safe, secure, high level work platform / staging up to 7.5 metres high. It complies with all the relevant British Standards and will fit on to (AND SHOULD ONLY BE USED WITH) any BS EN131 trade quality ladder.

DatasheetDatasheet

LADDER PLATFORM


Ladder Staging

Manufactured from strong, lightweight aluminium - cannot rust or corrode.

Can be erected in 6 minutes and taken down even faster!

From 2 metres in length
Up to 7.5 metres high

Iideal for replacing soffits, fascias and gutters.

USED ON A ROOF


Ladder Platform
 Compliance: - This system is manufactured to the requirements of the HSE and the relevant British Standard. Where neither the HSE or BSI provide a standard or a specification then the General Product Safety Regulations 1994 is used as a standard.

Safety: - The staging brackets have a safe working of 270 kg and will accept any make of 600 mm wide staging board.

LADDER PLATFORM DETAIL


Ladder Staging

LADDER PLATFORM DETAIL


Ladder Staging

The equipment consists of a handed pair of support brackets that mount onto your ladder and are attached two rungs apart

Each support bracket has a telescopic strut, which enables the support arm to be made horizontal very quickly and locked into position.

There are four corner posts that are rapidly locked into place on the staging brackets using captive thumb screws.

LADDER PLATFORM DETAIL


Ladder Staging

The corner posts are fitted with U bolts and L bolts to accept the hand rails and toe boards.

Finally the staging board is mounted across the support brackets and locked into place using the captive L bolts.

The 4 metre and 5 metre boards need a mid board post to support the hand rails.

Please refer to our datasheet at the top of the page for further details.
