air balancers - ingersoll rand


Ingersoll Rand Air Balancer

INGERSOLL RAND AIR BALANCER



The Ingersoll Rand air/pneumatic balancer is used as a hoist but offering some 'float' so the operator can manually position a component, for example, when locating an item on dowels.



The component is lowered near the desired position using the pendant control, accurately positioned by hand and then released using the pendant.



It can also be used as a tool balancer. The pendant control is removed and replaced by a pressure sensor that can be adjusted to equal out the load. This leaves the operator with a very easy to move tool that is accurately balanced.



Capacity: up to 227 kg *

Cable Length: 9144 mm (30 feet)

Stroke: 1 or 3 metres



* The full capacity is based on a 100 psi air supply, however, it can be used with a lower pressure. The capacity will reduce by 1% for every 1 psi below 100 psi.



Alternative control options are available that can sense whether the load is on or off and can be programmed to operate a clamp or grab accordingly.





Tool BalancerDatasheet



Air Chain Lifting Hoists



Air operated chain lifting hoists are similar in application to electric chain lifting hoists, the vane or piston operated motors maintain certain advantages according to the working environment and use.





Air Chain Hoists   Datasheet - Ingersoll Rand

Air chain hoists provide excellent power to weight ratios, especially at the higher capacities. Control options generally consist of direct mechanical rope, twist grip or a push button pendant. Other benefits of air lifting hoists include a variable speed control, no electrical circuitry, can be used in explosive environments and untroubled by unfriendly working conditions, i.e. dust, heat, humidity, etc.

The air chain lifting hoist can be supplied with a hook suspension as shown, or with a hand pushed, hand geared or air powered trolley.

Capacities: 1 tonne to 100 tonne

JDN MINI Standard Duty Air Chain Lifting Hoist


The mini air chain hoist widens the range of applications in the light duty sector as a handy, flexible and universally deployable hoist making it an ideal tool for the most different handicraft workshops.

For traversing loads there are different trolleys to meet your special demands.

Air Pressure: 6 bar

Capacities: 125 kg, 250 kg, 500 kg & 1000 kg

   Datasheet - MINI

The advantages at a glance:

  • Interesting and inexpensive alternative even to hoists with other driving media

  • Suitable for lube-free operation

  • Suitable for application in hazardous areas

  • Few components only for easiest maintenance

  • Wear resistant motor braking system light weight for easy handling

  • Also suitable for horizontal pulling

  • Extremely sensitive lever control with emergency shut-off valve, max. control length 6 m

  • Available lifting heights: 3m, 5m, 8m

  • With chain box as standard with manual trolley as option

JDN PROFI Heavy-Duty Air Chain Lifting Hoist


The profi air chain lifting hoist series are very robust and therefore suitable for tough industrial applications even in continuous working processes.

According to requirement there are various control systems.

For traversing loads there are different trolleys to meet your special demands.

Capacities: 1 tonne to 100 tonne

   Datasheet - PROFI

Standard features:

  • Suitable for application in hazardous areas

  • Sensitive infinitely variable speed control for the precise positioning of loads

  • Easy operation

  • Suitable for lube-free operation

  • Frequent switching and extended duty cycles

  • Low maintenance

  • Low headroom, lightweight

  • Sound absorption

  • Insensitive to dust, humidity and temperatures ranging form -20 °C up to + 70 °C

  • From 1 t upwards with overload protection (EC-version)

Technical Details:

  • Fail-safe starting chain sprocket in the mid section runs in dust proof maintenance free ball bearings g conditions, low maintenance vane motor

  • Planetary gear in long life grease lubrication, all teeth made of tempered or hardened high-grade steel

  • Chain and hook of high quality tempered steels with a breaking strength of five times the nominal load

JDN Trolleys


Air HoistAir HoistAir Hoist

JDN trolleys are available for all hoists of the PROFI and M series:

As manual trolleys (LN)
for pushing or pulling the trolleys by hand

As reel chain trolleys (LH)
for moving the trolleys by unwinding the reel chain

As motorised trolley (LM)
powered by an air motor

Capacities: 1 tonne to 100 tonne

Air Hoist   Datasheet - STANDARD TROLLEY

Air Hoist   Datasheet - LOW HEADROOM TROLLEY

Standard features:

  • Easy to install

  • Supplied with anti-climb and anti-drop devices

  • Robust and with little maintenance

  • Able to negotiate curves
